WC67K-400T/4000 Press Brake with Adjustable U-Shape Bending Tool

Views: 39     Author: Site Editor     Publish Time: 2022-09-13      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Main features

Colored drawing Design.

E21 NC Digital Controller.

SIEMENS Main Motor.

Foot Switch With Emergency Button.

Backgauge With Manual R-Axis.

Torsion Bar With Rack Structure.

Adjustable U shape Die.

Operating Demonstration.


The hydraulic bending machine includes a bracket, a worktable, and a clamping plate. The worktable is placed on the bracket. The worktable is composed of a base and a pressure plate. The base is connected to the clamping plate by a hinge. The base is composed of a seat shell, a coil, and a cover plate. The coil is placed in the recess of the seat shell, and the top of the recess is covered with a cover plate. When in use, the coil is energized by the wire, and after the electricity is energized, a gravitational force is generated on the pressure plate, to realize the clamping of the thin plate between the pressure plate and the base. Due to the use of electromagnetic force clamping, the pressing plate can be made into various workpiece requirements, and the workpiece with sidewalls can be processed.
