Features
Performance Features:
●Super large inertia wheel, large torque, high production capacity.
●High chromium tool steel, adjustable gap, durable
●Special V-shaped knife design, large cutting space, low heat
●Large feed port, can crush a variety of large plastic parts
●High-quality pure copper core motor, stable operation, low noise.
●Heavy-duty bearings and dustproof devices, and soundproof baffles, can effectively prevent vibration and noise
●All-steel frame and base, enhance the stability of the machine body.
Product Description
Specification
| Model | PC5060 | PC5070 | PC5080 | PC50100 | |
| 电机功率 Motor (kw) | 15 | 18.5 | 22 | 30 | |
| 动刀片 Moving blades (pcs) | 6 | 6 | 6 | 6 | |
| 定刀片 Fixed blades (pcs) | 4 | 4 | 4 | 4 | |
| 旋转直径 Rotating Φ Dia (mm) | 450 | 450 | 450 | 450 | |
| 进料口尺寸 Feeding inlet (mm) | 620x470 | 720X470 | 820X470 | 1000X470 | |
| 进料口高度 Feeding inlet (mm) | 1410 | 1415 | 1420 | 1500 | |
| 标准筛网孔径 Screen mesh Φ (mm) | 14 | 14 | 16 | 16 | |
| 粉碎能力 Crushing ability (kg/hr) | ≤550 | ≤700 | ≤900 | ≤1000 | |
| 机器重量 Weight (kg) | 900 | 980 | 1280 | 2000 | |
| 外形尺寸(mm) Dimensions (L*W*H) | 1360*1180*1846 | 1470*1280*1860 | 1520*1380*1880 | 1800*1750*2200 | |
