TP10 30ton 800
YSDCNC
Features
TP10 CNC system
TP10 CNC 10-inch TFT high-definition and high-contrast touch screen. The page is concise and the button operation is easier. Menu programming style, interface drawing, friendly. Language can be selected: Chinese, English. Support automatic calculation of bending angle and length. Support angle compensation and height compensation. Support picking function and mold management. The original multi-step bending sequence and products can be used. Strong reliability and strong anti-interference ability. Manual shifting and X/Y axis navigation and teaching functions.
Supports valve configuration and software limit functions.
Product Description
Specification
ITEM | VALUE |
Model | WC67K 30ton800 |
Pressure | 30ton |
Max bending length | 800mm |
Max bending thickness for 3.2m sheet | 3mm |
Column distance | 750mm |
Slide stroke | 100mm |
Throat depth | 300mm |
Main motor power | 3kw |
Machine size | 800x1000x800mm(L×W×H) |
Weight | 1000kg |
Axes | Y, X |
